Product Description

The ABB TH3222R is designed for commercial and industrial applications where safety and high performance are essential. This heavy-duty, two-pole, fusible disconnect switch is rated for 60A and 240V AC. It is suitable for use as service equipment when installed in accordance with the National Electrical Code. Enclosed in a NEMA 3R enclosure for outdoor use.

Designed for commercial and industrial applications
Listed to UL standard 98 enclosed and dead front switches
Quick-make, quick-break mechanism

Product Highlights

The ABB TH3222R fusible disconnect switch is ideal for heavy-duty applications requiring a reliable and safe disconnect solution. Suitable for commercial and industrial environments.

Product Information

Standard Information

Brand: ABB
Manufacturer Part Number: TH3222R
Country of Origin: UKN

Technical Specifications

Application: Heavy
Enclosure: NEMA 3R (Outdoor)
Voltage Rating: 240 AC
Amperage Rating: 60A
Number of Poles: 2
Harmonized Tariff Code: 8536509045
Category: Heavy Duty
Wires: 3
Fusing: Fusible
Wire Range (Cu/Al): 12-2
240 Vac, NEC Std, 1-ph: 3.0 hp
240 Vac, Time Delay, 1-ph: 10.0 hp
250 Vdc: 10.0 hp
GSA Compliance: Yes
cUL Listed: Yes
UL Listed: Yes
Enclosure NEMA Rating: NEMA 3R
Manufacturer: ABB
Component: Fusible Disconnect Switch
Current: 60 Amp
Poles: Two Pole
Enclosure Disconnect Type: Heavy Duty Safety Switch
Volts DC: 250
Mounting: Surface
Volts AC: 240
Amps: 60
IP/NEMA Rating: NEMA 3R

Brand	ABB
MPN	TH3222R

ABB TH3222R 60A 240V Two Pole Fusible Disconnect Switch
