The Following Items Are Included:

Fujikura 90R Ribbon Fiber Fusion Splicer (BC# 45324-L/T*)
CT-50 Precision Fiber Cleaver w/ Case (BC# 24580M-L/T*)
Fujikura RS03 Ribbon Stripper w/ DC Cable (BC# 24579M-L/T*)
Clauss CFS-2 Fiber Stripper
6 Month Fusion Splicer Care Kit FS6MC:
- 4oz Flip Jar Of 99% Alcohol
- (50) Non-Lint Dry Wipes
- (6) Fiber Optic Wipes w/ 99% Alcohol
- 2oz Pump Fast Evaporating Mirror Spray
- (25) Camera Swabs
- (25) V-Groove Swabs
FH-70-12 Fiber Holder Set
(2) AC Adapter/Chargers
(2) Power Cords
USB PC Interface Cable
User Manual On CD-ROM
Strap For Unit
Hard Carrying Case

BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS!

This Item Has A Current Calibration!

Fujikura 90R SM MM Ribbon Fiber Fusion Splicer

The Fujikura 90R ribbon splicer utilizes precision technology for splicing ribbon fiber up to 12 fibers, including single fibers.

User replaceable v-grooves!

Includes 6 Month Fusion Splicer Care Kit (FS6MC)
- 4oz Flip Jar Of 99% Alcohol
- (50) Non-Lint Dry Wipes
- (6) Fiber Optic Wipes w/ 99% Alcohol
- 2oz Pump Fast Evaporating Mirror Spray
- (25) Camera Swabs
- (25) V-Groove Swabs

Includes Fujikura CT-50 High Precision Fiber Cleaver, Hard Carrying Case & Accessories As Listed Above!

Working Condition: Excellent
Condition: Refurbished
Calibrated: Yes
Warranty: 1 YEAR WARRANTY

Fujikura 90R Fusion Splicer

Product Description
The Fujikura 90R is the mass fusion splicer workhorse of the splicing world. As data demand continues to rise, the solution to handle the increased traffic is to increase fiber counts. As a result, fiber counts being utilized in enterprise data centers, campus, and metro networks have grown enough to make single fiber splicing too costly and timely. High density cabling made possible by SpiderWeb Ribbon® (SWR) and others like it are spurring ribbon splicing activity in places that have traditionally used loose fiber. The 90R is the answer to these changes in splicing demand. With automated splice start, tube heater, wind protector, cleave tracking, and blade rotations for up to 2 cleavers at a time, this splicer frees up operator time for other fiber preparation steps. New to the 90R, you can keep your splicer in the field longer with field replaceable V-grooves. When V-grooves can no longer be cleaned after extended use, or are accidentally damaged, you can resume splicing in minutes by installing the spare set included with your 90R kit.

Features:
* Cleaver tracking and upkeep with wireless communication
* Automated wind protector, tube heater and splice operation
* User replaceable v-grooves
* 200 μm and 250 μm SWR universal ribbon prep accessories
* Graphical User Interface with 5.0" Touchscreen
* PC software and 90R manual downloaded from splicer
* Multi-function transit case with integrated workstation

Applications:
* Data Center cable installation
* High fiber count metro and campus networks
* Long-haul network installs and repair
* Trunk cable repair with Splice-on MPOs
* Ribbon splicing high density cables with 200 μm loose fiber

Specifications
Fiber Alignment Method	Self cladding alignment with melting surface tension
Fiber Count Can Be Spliced	Up to 16 fiber ribbon
Applicable Fiber
Fiber Type	Single Mode Fiber Multi Mode Fiber
Cladding Dia.	Approx. 125 μm
Applicable Coating
Sheath Clamp	Coating Shape: Refer to options Cleave length: 10mm
Fiber Splice Performance
Splice Loss	ITU-T G.652 : Avg. 0.05 dB ITU-T G.651 : Avg. 0.02 dB ITU-T G.653 : Avg. 0.08 dB ITU-T G.655 : Avg. 0.08 dB ITU-T G.657 : Avg. 0.05 dB
Splice Time	SM FAST mode : Avg. 14 to 15 sec. SM AUTO mode : Avg. 19 to 20 sec.
Applicable Protection Sleeve
Sleeve Type	Heat-shrinkable sleeve
Sleeve Length	Max. 66 mm
Sleeve Dia.	Max. 6.0 mm before shrinking
Sleeve Heat Performance
Heat Time	40 mm FP-05 mode : Avg. 38 to 40 sec. 40 mm FP-04T mode : Avg. 17 to 19 sec. Single 60 mm mode: Avg. 13 to 15 sec.
Fiber Tensile Test Force	Approx. 2.0 N
Electrode Life	Approx. 1,500 splices
