Product Description

ABB Installation Products 54174 is a Color-Keyed 1-hole non-insulated compression lug designed for 250 kcmil copper conductors. The lug features die code 62, a peep inspection hole, and fits a 3/8 in stud. It is constructed of high-conductivity copper with tin plating, has a straight tongue and standard barrel (0.77 in diameter), and is rated to 35 kV AC with CSA and UL listings.

1-hole non-insulated compression lug for stranded copper up to 250 kcmil, die code 62 with peep inspection hole
High-conductivity wrought copper construction with tin plating, straight tongue and standard barrel (0.77 in dia), overall length 2.28 in
Fits 3/8 in stud, rated to 35 kV AC, certified to CSA and UL standards

Product Highlights

Color-Keyed die code 62 compression lug for 250 kcmil copper conductors with peep inspection hole and tin-plated standard barrel.

Product Information

Standard Information

Brand: ABB INSTALLATION PRODUCTS
Manufacturer Part Number: 54174
Country of Origin: Mexico

Technical Specifications

Brand: ABB Installation Products
MPN: 54174
Series: 54100
Product type: One-hole compression lug
Type: 1-Hole Non-Insulated
Conductor Size: 250 kcmil
Conductor Material: Copper
Material: High-conductivity wrought copper
Plating: Tin plated
Die Code: 62
Stud Size: 3/8 in
Hole Count: 1
Peep Hole: Yes
Tongue Type: Straight
Tongue Dimensions: 0.93 in L x 1.13 in W x 0.14 in thickness
Overall Length: 2.28 in
Barrel Type: Standard barrel
Barrel Diameter: 0.77 in
Mounting Hole Size: 0.406 in
Voltage Rating: 35 kV AC
For Wire Type: Stranded copper
Mounting Type: Bolt
Termination: Crimp
Standards/Certifications: CSA certified, UL listed
Orientation: Straight
Country of Origin: Mexico
Package Weight: 0.1 lb
UPC: 786210541747
GTIN: 00786210541747

Brand	ABB INSTALLATION PRODUCTS
MPN	54174

ABB 54174 Compression Lug 250 kcmil 1-Hole 3/8" Stud Copper
