Hygielock New Open Box KL3-SS Solenoid Locking Interlock Switch KL3-SS-205005. Shipped with USPS Ground Advantage.

HYGIELOCK KL3-SS.

The KL3-SS Series Guard Locking Switches have a rugged Stainless Steel 316 body and have been developed with a holding force of 2000N (200kg) to keep medium to large Guard Doors closed until hazards have been removed.

They are designed in accordance with EHEDG Guidelines for hygienic design (EHEDG European Hygienic Engineering Design Group). The mirror polished surface to Ra10 is designed to cope with direct food splash and cleaning found in the tough applications of the Food Processing Industries. They have IP69K enclosure protection and can be high pressure hosed with detergent at high temperature.

They have a slim body design under 50mm wide and can be fitted to 50mm (2inch) frame sections or to applications where space is restricted. The Head will rotate to provide up to 8 actuator entry positions.

Specifications:

Standards:

ISO14119

EN60947-5-1

EN60204-1

ISO13849-1

EN62061

UL508

Safety Classification and Reliability Data:

Mechanical Reliability B10d: 2.5 x 106 operations at 100mA load

ISO13849-1: Up to PLe depending upon system architecture

EN62061: Up to SIL3 depending upon system architecture

Safety Data – Annual Usage: 8 cycles per hour/24 hours per day/365 days

PFHd: 3.44 x 10-8

Proof Test Interval (Life): 35 years

MTTFd: 356 years

Solenoid Voltage (by Sales Number): 24V ac/dc or 110Vac or 230Vac

Solenoid Wattage: 12W

LED 2 Supply Voltage: 24Vdc

Utilization Category: AC15 A300 3A

Thermal Current (lth): 5A

Rated Insulation/Withstand Voltages: 600Vac/2500Vac

Travel for Positive Opening: 10mm

Actuator Entry Minimum Radius: 175mm Standard; 100mm Heavy Duty

Maximum Approach/Withdrawal Speed: 600mm/s

Holding Force: F1Max 2000N Fzh 1538N

Body Material: Stainless Steel 316

Enclosure Protection: IP67; IP69K

Operating Temperature: -25°C ~ 80°C

Vibration:

IEC 68-2-6 10-55Hz + 1Hz

Excursion 0.35mm 1 octave/min

Fixing: 4 x M5

Brand	Hygielock
Packaging	Box
